ACCU-SCOPE RC500

Magnification Range

4x–100x (standard: 4x, 10x, 20x, 40x, 60x; optional: 10x, 20x, 40x, 50x, 60x, 100x)

Numerical Aperture (NA)

0.9 (Abbe condenser)

Resolution

Camera 8.1MP or 2.3MP color; global shutter; full optical res. up to 100x

Field of View (FOV)

WF10x/22mm eyepieces; software allows 10%, 30%, 90% sample motion

Depth of Field

Not specified

Contrast Methods

Brightfield only; Fluorescence N/A

Optical System Type

Infinity Optical System, f = 200mm

Motorized Components

Motorized nosepiece, focus, stage; remote controllable

Automated Imaging Sequences

Systematic Field Screening, Slide Scanning

Software for Image Analysis

Image annotation, measurement; INFINITY ANALYZE 7 available

Remote Operation Capability

Full remote control: objectives, stage, illumination, capture, annotate; needs internet & PC

Data Export Formats

Not specified

Integration with Laboratory Information Systems (LIS)

Not specified

Ergonomic Design

Viewing head 30° incline, 360° rotatable; interpupillary 47–78 mm; right-handed XY controls

Modular Expandability

Optional objectives; other accessory compatibility not detailed

Maintenance Requirements

Not specified

Power Supply Specifications

100–240V, 1.5A

Product Series

RC500 Remote Collaboration System (Upright Microscopes)

Technical Support Availability

Manuals, videos, Micro-Mentor, distributor/service centers, software, warranty, FAQs
