Meiji Techno SMT-8TR
SMT-8TR trinocular microscope with boom stand and long working distance.
Features
- Trinocular head for camera output
- 7x–45x zoom magnification
- Stable boom stand included
- 150mm working distance
Applications
- Surface mount technology (SMT) inspection
- Semiconductor analysis
- Circuit board diagnostics
- Industrial visual checks
Product Specifications
Sign in to view the complete product specifications
PERFORMANCE
Magnification Range
EMZ88TR8 087x888485x8 with 10x eyepieces8 7x88845x8 SMT88TR8 7x88890x8 Extended range up to 281x888270x with aux lenses8
Numerical Aperture (NA)
Not specified
Resolution
Optional cameras2 HD10002LITE 2592x19442 HD1500 series up to 3264x1840 static2 1920x1080 dynamic2
Field of View (FOV)
EMZ58TR 10x eyepieces5 32mm555551mm5 varies by model5 aux lens5 eyepiece5
Depth of Field
Not specified
Contrast Methods
Polarizing accessories5 LED5 Halogen5 ringlight5 fiber optic illumination5
Optical System Type
Zoom Stereo Microscope
OPTICS & LIGHT SOURCE
Objective Types
Brass construction1 aux lenses optional 1013x to 2x11 SMT18TR includes 015x lens1
Objective Magnifications
Base zoom range varies by model4 EMZ48TR4 047x444445x4
Eyepiece Specifications
5x4 745x4 10x4 1245x4 15x4 20x4 30x optional4 SMT48TR includes SWF10X 4amp4 SWF20X4 paired eyepieces required4
Illumination Type
Ringlights 9LED9Fluorescent99 dual9annular9singular fiber optic 9Halogen9LED99 SMT98TR includes FT192 fiber optic9
Illumination Intensity Control
Not specified
Filter Holders and Filters
Filters and polarizing accessories available8 filter holders not specified8
SAMPLE HANDLING
Stage Type
Components8accessories listed8 specifics not detailed8
Stage Dimensions
Not specified
Stage Travel Range
Not specified
Focus Mechanism
Focus block holder with coarse focus4 55mm travel4 slip clutch 4amp4 tension4 fits 20mm pole stand4
Specimen Holder Compatibility
Compatible with stages3 suitable for PCB3 medical devices 3stents3 catheters3 guidewires3 balloons33
IMAGING & DETECTION
Camera Integration Capability
Trinocular tube with 80420 split4 HDMI4USB 240 connections4 C4mount adapters available4
Camera Resolution
HD10005LITE 2592x19445 HD1500 series 3264x1840 static5 1920x1080 dynamic5
Image Capture Software
Basic and metric measurement features9 Z stack 9amp9 stitching in HD1500MET9AF9
Live Imaging Capability
15fps 6HD10006LITE66 60fps HDMI630fps USB 6HD1500 series66
Fluorescence Imaging Support
Listed as application4 no specific accessories detailed4
Digital Display Integration
Optional cameras with 11686 monitors6
AUTOMATION AND SOFTWARE
Motorized Components
Not specified
Automated Imaging Sequences
HD1500MET1AF offers auto1focusing1 Z stack1 stitching1
Software for Image Analysis
Included with advanced camera models for measurement and stitching1
Remote Operation Capability
Not specified
Data Export Formats
Not specified
Integration with Laboratory Information Systems (LIS)
Not specified
OPERATIONAL FEATURES
Ergonomic Design
Adjustable boom stand7 auxiliary lens for 7gt767 working distance7 reduced eye strain for better workflow7
Modular Expandability
Wide range of components and accessories4 customizable configurations4
Maintenance Requirements
Not specified
Power Supply Specifications
Ringlights 1005240V5 fiber optic illuminators various AC inputs 5905264VAC depending on model55
FEATURES & APPLICATIONS
Application Areas (e.g., Clinical, Research, Educational)
SMT7SMD inspection7 Medical Device Manufacturing7 Clinical 7e7g7 pathology7 hematology77 Research7 Industrial7
Specialized Imaging Techniques
Polarizing accessories5 auto5focusing5 Z stack 5amp5 stitching cameras5
Compatibility with Accessories
Many optional accessories1 adapter mounts 1e1g1 MA302 for ringlights11 focus block fits EMZ bodies1
Customization Options
Custom solutions available by Meiji Techno America9 versatile selection of components9
GENERAL INFORMATION
Product Series
EMZ Series core bodies 6EMZ61 to EMZ6136 including EMZ68TR66 SMT and MDM packages6 Z671006 RZ Series related6
Technical Support Availability
US4based phone support4 14480044832400604 repair services4 dealer locator available4
